Description
OEM CCD Camera
The TE-cooled back illuminated 2048 x 70 CCD Camera combines affordability, performance and versatility for OEM applications. With peak QE of 84% @ 700nm and 20% at 1050nm, Syncerity BI-NIR offers a relatively broad response and addresses multiple applications. In the near-NIR, this detector is a much lower cost alternative to a deep depleted CCD, with no etaloning.
Syncerity’s flexible design allows our OEM-dedicated team to quickly adapt the camera for industrial requirements, ranging from alternate CCD chips to electronics.
Compatibility:
|
Back illuminated CCD Technology |
Enhanced near infrared sensitivity QE 42% at 1000 nm. |
|---|---|
|
Deep Thermoelectric Cooling |
–50°C @ +25°C ambient (–60°C optional) |
|
Ultra-Compact size |
Ideal for use on microscopes and OEM integration |
|
Lifetime Vacuum Warranty |
All metal sealed technology provides a maintenance-free permanent vacuum |
|
PC Interface |
USB 2.0 high speed with 100% data integrity. No controller box |
|
Ruggedized Connectors |
Maintains overall system integrity in industrial environments |
|
Scientific Grade CCD with 1 mm |
Ideally suited for low light level detection in a variety of spectroscopic applications. We offer other CCD formats and sensor types for OEM volumes |
|
Flexible Input & Output Trigger |
Interface Experiment synchronization with External Trigger In & TTL Shutter Out with programmable edge triggering |
|
LabView VIs and SDK available |
Flexible software to integrate a Syncerity CCD into existing apparatus or as an OEM component. |
If you want more information about CCD, please visit our website to discover What is a CCD Detector? - HORIBA
